Temperature range: - 40 ℃ - + 85 ℃
Rated voltage: 500V AC
Rated current: 1-15a (determined according to the specific cable)
Contact resistance: ≤ 10m Ω
Insulation resistance: ≥ 10m Ω under normal and wet conditions
Withstand voltage: AC 800V 50Hz, no breakdown or flashover for 1 minute
Contact: copper alloy tinning / gold plating
Protection grade: IP66
Mechanical life: 200 times
Maximum outer diameter: plug 10 mm, socket 12 mm
Total matching length: 78mm
Specification of conductor used: 1.2mm? 2.0mm
Application scope: power connection and signal transmission for electronic and electrical equipment (commonly used for connection between battery and controller)
